Why is 50% the Threshold Limit for Particle Counting Efficiency?

Particle counting efficiency is very important in particle measurements, especially when using optical particle counters. This term denotes the possibility of precisely detecting and counting particles in a given size spectrum. In this context, the term “particle counting efficiency” represents the ability of a particle counter to accurately measure particles of a certain size. It measures instrument performance, showing how effectively the instrument can detect and count particles of various sizes.

The importance of particle counting efficiency lies in its direct impact on the reliability and accuracy of particle measurements. For example, in applications such as air quality monitoring, pharmaceutical manufacturing, or aerosol science research, precision in measuring particle size and concentration is paramount. Higher counting efficiency means the counter is more effective at detecting and counting particles within a specified size range, resulting in more accurate and reliable data.

When discussing “efficiency measure thresholds” for optical particle counters, a 50% threshold is the standard benchmark. Of course, the 100% calculation efficiency test is carried out at sizes larger than the first threshold, as mandated in ISO 21501-4. This makes sense for overall optical efficiency. However, our article will focus on why 50% was chosen as the threshold for calculating the efficiency measure threshold in optical particle counters. That way, you can apply it in various situations. This includes cleanroom particle counting as an air quality monitoring solution.

Principles of Particle Counting Efficiency

Particle counting efficiency in an optical particle counter is defined as the probability of the device accurately detecting and counting particles as they traverse the sample volume of the counter. It indicates the percentage of particles calculated at or above a certain size.

Probability is critical in ensuring the accuracy and reliability of particle counting, especially in environments where particle size distribution is an important parameter. This includes monitoring cleanrooms and various industrial processes, as continuous monitoring is required to measure particles and ensure clean air.

50% Threshold Requirement.

The 50% particle counting efficiency size threshold represents the balance point in the ability of an optical particle counter to detect particles at its most sensitive size limit. Real-world optical particle counters exhibit a range of resolutions that influence their efficiency curves. Unlike hypothetical optical particle counters with perfect resolution, real-world devices exhibit asymmetric efficiency curves. This is due to the exponential relationship between particle size and the resulting signal.

• Consistency in Sensitivity: Choosing a particle counting efficiency level of 50% for the most sensitive threshold ensures uniformity across optical particle counters with different resolutions. This standardization is important for meaningful comparison of optical particle counter data with reference standards and other particle counters.

• Minimizing Resolution Dependencies: By adopting a threshold of 50%, the impact of variations in sensor resolution on determining the most sensitive threshold can be minimized. This approach avoids nominal threshold shifts that would occur at different levels of calculation efficiency. Ultimately, this can ensure more accurate and consistent particle sizing.

• Harmonization with Calibration Standards: The 50% threshold is in line with industry standard calibration procedures. This threshold is particularly important in the context of ‘half count’ calibration.

The half-count calibration process involves particles with a narrow size distribution that corresponds to the size threshold of the optical particle counter. By using these calibrated standards, optical particle counters will provide consistent and comparable results.

• Impact on Real World Particle Distribution: In actual particle distribution, the calculation efficiency of the optical particle counter affects the accuracy of particle size measurement. This is broader than the distribution of monodisperse particles. A computational efficiency measure threshold of 50% allows a more accurate representation of this distribution. This includes situations where the particle concentration increases rapidly as the particle size decreases.

Optical Particle Counters Require a Counting Efficiency Measure Threshold of 50% to Produce Excellent Results

A particle counting efficiency size threshold of 50% in optical particle counters can improve the accuracy, consistency and reliability of scattered light particle size measurements. Using thresholds, measurements can:

• Overcoming the inherent limitations of real-world optical particle counters
• Ensure comparison with reference standards
• Adapts to a wide variety of particle distribution properties encountered in a variety of industrial and scientific applications.

In summary, the size threshold of 50% particle counting efficiency in an optical particle counter is an important parameter that balances the need for accuracy and consistency in particle size. Efficiency measure threshold calculations ensure reliable data in a wide range of applications, such as for environmental monitoring systems, as well as particle counters in cleanrooms and handheld particle counters.

For more information about environmental monitoring systemor other related topics, such as ISO 14644-1live particles or flow rate influences, please contact an expert at Particle Measurement Systems. They will be happy to help you find the real-time measurement system that best suits your project.
